| 標準直徑 NominalΦ | 內徑 Inside | 螺旋纏繞層直徑 WireΦ | 外徑 OutsideΦ | 工作壓力 Working pressure | 檢測壓力 Test pressure | 爆裂壓力 Burst pressure | 彎曲半徑 Bend radius | 重量 Weight | ||
|---|---|---|---|---|---|---|---|---|---|---|
| lcnch | mm | mm | mm | mm | bar | psi | bar | bar | mm | kg/m |
| 3/8 | 10 | 9.5 | 17.5 | 21.4 | 445 | 6455 | 1070 | 1780 | 180 | 0.78 |
| 1/2 | 12 | 12.7 | 20.2 | 24.6 | 425 | 6165 | 1020 | 1700 | 230 | 0.93 |
| 5/8 | 16 | 15.9 | 23.8 | 28.2 | 350 | 5075 | 840 | 1400 | 250 | 1.17 |
| 3/4 | 19 | 19.0 | 28.2 | 32.2 | 350 | 5075 | 840 | 1400 | 300 | 1.48 |
| 1 | 25 | 25.4 | 35.3 | 39.7 | 280 | 4060 | 670 | 1120 | 340 | 2.02 |
| 1-1/4 | 31 | 31.8 | 46.0 | 50.8 | 210 | 3045 | 500 | 840 | 460 | 3.05 |
| 1-1/2 | 38 | 38.1 | 52.4 | 57.2 | 185 | 2685 | 445 | 740 | 560 | 3.52 |
| 2 | 51 | 50.8 | 65.3 | 69.8 | 165 | 2395 | 395 | 660 | 660 | 5.20 |
